CUSTOM DRINKING WATER FILTRATION SYSTEM
100% organic water treatment. No chemicals!
PLC controlled water filtration system.
4000 liters (1000gal) per hour (99.9999% sanitized water)
- The operating life of UV-C lamps is 10,000 hours.
4 UV-C° lamps (4×42 w)
Ozone production: =2 g/h
Disinfection capacity – 54 m3/h (30-50 millijoules/cm2) 230 GPM
BACTERIOLOGICAL TREATMENT: Ozonization with a pressurized contact tank. Double UV-C treatment chambers. Ozone destroyer.
Safe and sanitized drinking water
- Filtration:
- Ultra filtration
- Ozonization
- Double UV-C treatment chambers
- Ozone destroyer
- Active Carbon
- WQA Certified NSF/ANSI std 42 & 53 for reduction of PFOA/PFOS, Total Trihalomethanes, VOC's, MTBE, Lead, Cysts, Turbidity, Aesthetic Chlorine & Chloramines, Class 1 Particulate 1/2 micron, Tastes/Odors.
- U. S. EPA performance tested, evaluated and verified for bacteria, virus and protozoan cysts reduction to Federal Guidelines for Drinking Water purification.
High end manufacturing
Custom 304 stainless steel welded frame
SCH 80 PVC plumbing components
- Ultra-silent water pump with pressure switch to maintain a constant flow of 1,000 to 4,000 litres/hour* with a pressure of 3.5 bars, even if the inlet filters are partially clogged the flow and pressure are maintained.
- Thanks to its complex electronic management it turns on only when it detects the passage of water, without the risk of leaving a portion of the water without treatment, unlike other UV-C systems of water treatment, which remain on 24/7.
Optional prefilter
- No Chemicals!
- Removes particles up to 1µm as well as dissolved organic components, hydrocarbons, and micro-plastics.
- Effective removal of most protozoa, fungae, Cryptosporidium and bacterial flocs.
- Superior mechanical filtration up to 4µm particles (98% removal).
- Adsorption of positively charged particles, flocs and metals (Fe, Mn, As).
- NSF-61 certified for use in drinking water treatment.
- HACCP certified for food & beverage production.
HOME DRINKING WATER FILTRATION SYSTEM
100% organic water treatment. No chemicals!
WTS-I
PLC controlled water filtration system.
99.9999% sanitized water
Production: 600 litres (150gal) per hour
Production: 14,400 litres (3800 gal) per day
French Sanitary Conformity Certificate
- Filtration:
- Self-cleaning pre-filter
- UV-C treatment
- UF filter with flushing valve
- Active Carbon
- Chemical reduction cartridge
- Anti-microbial cartridge
- Weight: 58 kg
- Size: L46 x W43 x H135 cm.
- Stainless steel welded frame
- The operating life of UV-C lamps is 10,000 hours.
100% organic water treatment. No chemicals!
WTS-II
PLC controlled water filtration system.
99.99% sanitized water
Production: 1,500 litres (400gal) per hour
Production: 36,000 litres (9500gal) per day
French Health Compliance Certificate
- Filtration:
- Self-cleaning pre-filter***
- UV-C treatment
- UF filter with flushing valve
- Active Carbon
- Chemical reduction cartridge
- Anti-microbial cartridge
- Weight: 102 kg
- Size: L84 x W62 x H158 cm
- Stainless steel welded frame
- The operating life of UV-C lamps is 10,000 hours.
100% organic water treatment. No chemicals!
WTS-III
PLC controlled water filtration system.
99.99% sanitized water
Production: 3,000 litres (800gal) per hour
Production: 72,000 litres (19,000gal) per day
French Sanitary Conformity Certificate
- Filtration:
- Self-cleaning pre-filter***
- UV-C treatment
- UF filter with flushing valve
- Active Carbon
- Chemical reduction cartridge
- Anti-microbial cartridge
- Weight: 310 kg
- Size: L90 x W86 x H190 cm
- Stainless steel welded frame
- The operating life of UV-C lamps is 10,000 hours
Sediment Prefilter
- No Chemicals!
- Removes particles up to 1µm as well as dissolved organic components, hydrocarbons, and micro-plastics.
- Effective removal of most protozoa, fungai, Cryptosporidium and bacterial flocs.
- Superior mechanical filtration up to 4µm particles (98% removal).
- Adsorption of positively charged particles, flocs and metals (Fe, Mn, As).
- NSF-61 certified for use in drinking water treatment.
- HACCP certified for food & beverage production.
Sediment Prefilter Benefits
- Provides exceptional water clarity: Certified 1 micron filtration (w/o flocculation)
- Certified potable water use (NSF 50/61), food & drinks markets (HACCP)
- Prevents the formation of harmful disinfection byproducts (THMs, NCl3)
- Offers substantial water and energy savings thanks to shorter and slower backwashes.
- Offers substantial water and energy savings thanks to shorter and slower backwashes.
- Fully prevents bacterial growth, bio coagulation and channeling in the filter bed.
Polishing
- Stage 1: WQA Certified NSF/ANSI std 42 & 53 for reduction of PFOA/PFOS, Total Trihalomethanes, VOC's, MTBE, Lead, Cysts, Turbidity, Aesthetic Chlorine & Chloramines, Class 1 Particulate 1/2 micron, Tastes/Odors.
- Stage2: U. S. EPA performance tested, evaluated and verified for bacteria, virus and protozoan cysts reduction to Federal Guidelines for Drinking Water purification.
Cartridge 1: Chemical Reduction Cartridge
- Certified NSF/ANSI Std 42 & 53
- 5 Stage Patented Exclusive High Flow Design
- Adsorption - specially formulated high-capacity powder activated carbon block with over 1,000,000 square meters of adsorptive surface area.
- Built in 5-micron pre filter and scale control media.
Cartridge 2: CMF Charged Membrane Filter Microbial Retention
- Performance testing, evaluation & verification completed at US EPA testing & evaluation facility Cincinnati, OH & BCS laboratory 3rd party accredited Lab.
- CMF microbial media - NSF/ANSI Std 42 & 61, USP Class VI
- CMF microbial cartridge- Tested to USEPA/NSF Std P231
- Filters have been performance tested, evaluated and verified by the USEPA T & E Facility & 3rd Party Independently for: MS2 Bacteriophage Virus >99.9% Adenovirus 92% Cryptosporidium 99.9992% RT Bacteria >99.99% Bacillus globigii 99.8% Endotoxins 96.0% Legionella >99.9%.
Multi-Barrier Drinking Water system trailer
100% organic water treatment. No chemicals!
WATER TRAILER
PLC controlled water filtration system.
99.9999% sanitized water
Production: 600 litres (150gal) per hour
Production: 14,400 litres (3800 gal) per day
French Sanitary Conformity Certificate
- Filtration:
- Self-cleaning pre-filter removing particles up to 1µm as well as dissolved organic components, hydrocarbons, and micro-plastics.
- Adsorption of positively charged particles, flocs and metals (Fe, Mn, As).
- UV-C treatment
- UF filter with flushing valve
- Active Carbon
- Chemical reduction cartridge
- Anti-microbial cartridge
- Runs off generator or solar power.
